Acoustic Doors & Frames
Rigorously tested to achieve exceptional sound reduction values, our acoustic doors and frames deliver proven performance with sophisticated design.
Non-fire rated
- Up to 44dB acoustic rating
- FIS verified
- Hand-finished timber
Choose from our range of acoustic door assemblies featuring a high-quality face finish with bespoke handcrafted real wood veneers or commercially available high-performance laminates.
Suitable for internal use and designed to meet acoustic performance standards, this product complies with BS EN ISO 717-1: 1997 & 2013.
Our acoustic doors can be fitted into a variety of frames and partitions, we’ll work closely with you and other partners to find the best solution for your design.
Vision panels are fitted with glass to achieve acoustic performance standards as per manufacturer instructions. Additional vision panel styles, including circular, Vistamatic, and rounded Slimline, are also available.
Technical Specifications
Customisation
Vision Panels
Frames
Forza frames are typically made from hardwood (Min density 450 Kg/m³) to achieve maximum acoustic performance. Other frame types are available, but this will impact the acoustic ratings that can be achieved.
Whatever the material, we can perfectly match your doors to your frames for a seamless finish.
Delivery options: Available assembled, unassembled or pre-assembled and disassembled for transport purposes.
Elevations
Browse our ready-made acoustic elevation options below, or speak to our experts about creating bespoke door assemblies with overpanels, sidelights and fanlights. Though not covered in our standard acoustic guides, we'll help you craft the perfect solution.
Ironmongery
Ironmongery compatibility check & guidance: we will check whether your ironmongery is compliant and advise if you need to make a change to your design.
Milling service: we offer machine-finished precise milling for all your locks, hinges, closers and more, be sure to include it in your quote request.
Please note - Any recessed millings in the door core or frame detail will alter the acoustic rates.
Seals
FD30 Acoustic
- Up to 35dB acoustic rating
- FIS verified
- 30 minute fire rating
Choose from our range of FD30 fire-rated acoustic door assemblies featuring a high-quality face finish with bespoke handcrafted real wood veneers or commercially available high-performance laminates.
Designed to meet acoustic performance and fire-rated standards, the product complies with BS EN ISO 717-1: 1997 & 2013 and BS 476-22 fire resistance regulations, providing 30 minutes of fire protection as a non-load-bearing system.
Our acoustic doors can be fitted into a variety of frames and partitions, we’ll work closely with you and other partners to find the best solution for your design.
Vision panels are fitted with laminated glass to achieve FD30/0 FD30/30 and acoustic performance standards as per manufacturer instructions. Additional vision panel styles, including circular, Vistamatic, and rounded Slimline, are also available.
Technical Specifications
Customisation
Vision Panels
Frames
Forza frames are typically made from hardwood (Min density 450 Kg/m³) to achieve maximum acoustic performance. Other frame types are available, but this will impact the acoustic ratings that can be achieved.
Whatever the material, we can perfectly match your doors to your frames for a seamless finish.
Delivery options: Available assembled, unassembled or pre-assembled and disassembled for transport purposes.
Elevations
Browse our ready-made FD30 acoustic elevation options below, or speak to our experts about creating bespoke door assemblies with overpanels, sidelights and fanlights. Though not covered in our standard acoustic guides, we'll help you craft the perfect solution.
Ironmongery
Ironmongery compatibility check & guidance: we will check whether your ironmongery is compliant and advise if you need to make a change to your design.
Milling service: we offer machine-finished precise milling for all your locks, hinges, closers and more, be sure to include it in your quote request.
Please note - Any recessed millings in the door core or frame detail will alter the acoustic rates.
Seals
FD60 Acoustic
- Up to 44dB acoustic rating
- FIS verified
- 60 minute fire rating
Choose from our range of FD60 fire-rated acoustic door assemblies featuring a high-quality face finish with bespoke handcrafted real wood veneers or commercially available high-performance laminates.
Designed to meet acoustic performance and fire-rated standards, the product complies with BS EN ISO 717-1: 1997 & 2013 and BS 476-22 fire resistance regulations, providing 60 minutes of fire protection as a non-load-bearing system.
Our acoustic doors can be fitted into a variety of frames and partitions, we’ll work closely with you and other partners to find the best solution for your design.
Vision panels are fitted with laminated glass to achieve FD60/0 FD60/30, FD60/60 and acoustic performance standards as per manufacturer instructions. Additional vision panel styles, including circular, Vistamatic, and rounded Slimline, are also available.
Technical Specifications
Customisation
Vision Panels
Frames
Forza frames are typically made from hardwood (Min density 450 Kg/m³) to achieve maximum acoustic performance. Other frame types are available, but this will impact the acoustic ratings that can be achieved.
Whatever the material, we can perfectly match your doors to your frames for a seamless finish.
Delivery options: Available assembled, unassembled or pre-assembled and disassembled for transport purposes.
Elevations
Browse our ready-made acoustic elevation options below, or speak to our experts about creating bespoke door assemblies with overpanels, sidelights and fanlights. Though not covered in our standard acoustic guides, we'll help you craft the perfect solution.
Ironmongery
Ironmongery compatibility check & guidance: we will check whether your ironmongery is compliant and advise if you need to make a change to your design.
Milling service: we offer machine-finished precise milling for all your locks, hinges, closers and more, be sure to include it in your quote request.
Please note - Any recessed millings in the door core or frame detail will alter the acoustic rates.
Seals
Popular Veneers & Finishes
Niveus
Eucalyptus
Terracotta
F4161
American Black Walnut
Walnut
Albus
Ash
Artichoke
F0800
Reed Green
U599 PM
Piceus
Ash
Imber
Mulitilaminar (Oak)
Terra
Ash
Misty Blue
U502 ST9
Olive Ash
Ash
Solid Cashmere Grey
U7021 ST9
Crown Cut Beech
Beech
Vesperi
Multilaminar (Poplar)
Aged Ash
F8844
Furvus
Ash
Rotary Cut Kevasingo
Kevasingo
Alpino
F1040
White Elm
Elm
Macassar Ebony
EbonyGet inspired
Acoustic Doors FAQs
Can you cut aperture holes on a flush door leaf on-site?
Letterbox, door viewer, air transfer grills must be tested or otherwise approved for use with Forza fire-rated doors, they must be fitted fully in accordance with manufacturer instructions including all intumescent liners and cloaking grilles/beads.
Restrictions on the maximum size and placement of any aperture, in which must also be included in the total area permitted for apertures.
Note: the installation of such items in a door leaf may compromise its performance as a smoke control door assembly.
I need EN tested doors, are your doors EN tested?
At this moment Forza is only permitted to certify fire-rated door assemblies under BS 476: 22.
We are actively developing a scope of fire-rated products under EN 1634-1.
Acoustic Doors & Frames - Single Door Specifications
TIMBER (or MDF) FRAMES
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Code | dBRw | Core | Fire | Leaf | Drawing ref | |
|---|---|---|---|---|---|---|
| SG44.32AS | 32 | 44 | N/F | Flush | FZD0715 | |
| SG44.34AGS | 34 | 44 | N/F | V/P | FZD0716 | |
| SG44.32A30S | 32 | 44 | 30 Min | Flush | FZD0717 | |
| SG44.34A30GS | 34 | 44 | 30 Min | V/P | FZD0718 | |
| SG54.35AS | 35 | 54 | N/F | Flush | FZD0719 | |
| SG54.35AGS | 35 | 54 | N/F | V/P | FZD0720 | |
| SG54.35A60S | 35 | 54 | 30/60 Min | Flush | FZD0721 | |
| SG54.35A60GS | 35 | 54 | 30/60 Min | V/P | FZD0722 | |
| SGFK54.37AS | 37 | 54 | N/F | Flush | FZD0732 | |
| SGFK54.37AGS | 37 | 54 | N/F | V/P | FZD0733 | |
| SGFK54.37A60S | 37 | 54 | 60 Min | Flush | FZD0734 | |
| SGFK54.37A60GS | 37 | 54 | 60 Min | V/P | FZD0735 | |
| SGFS54.40AS | 40 | 54 | N/F | Flush | FZD0736 | |
| SGFS54.40AGS | 40 | 54 | N/F | V/P | FZD0737 | |
| SGFS54.40A60S | 40 | 54 | 60 Min | Flush | FZD0738 | |
| SGFS54.40A60GS | 40 | 54 | 60 Min | V/P | FZD0739 | |
| SGFS59.43AS | 43 | 59 | N/F | Flush | FZD0740 | |
| SGFS59.39AGS | 39 | 59 | N/F | V/P | FZD0741 | |
| SGFS59.43A60S | 43 | 59 | 60 Min | Flush | FZD0742 | |
| SGFS59.39A60GS | 39 | 59 | 60 Min | V/P | FZD0743 | |
| SGFP64.38AGSS | 38 | 64 | N/F | V/P | FZD0796 | |
| SGFP64.39AGSS | 39 | 64 | N/F | V/P | FZD0797 | |
| SGFP64.40AGSD | 40 | 64 | N/F | V/P | FZD0804 | |
| SGFP64.41AGSD | 41 | 64 | N/F | V/P | FZD0805 | |
| SGFH64.36A120S | 36 | 64 | 120 Min | Flush | FZD0798 |
ALUMINIMUM FRAME
|
|
|
|
|
| Code | dBRw | Core | Fire | Leaf | Drawing ref | |
|---|---|---|---|---|---|---|
| ASG44.32A30S | 32 | 44 | 30 Mins | Flush | FZD0793 | |
| ASG44.34A30GS | 34 | 44 | 30 Mins | V/P | FZD0794 | |
| ASGFS44.35AS | 35 | 44 | N/F | Flush | FZD0795 |
Acoustic Doors & Frames - Double Door Specifications
Acoustic Summary
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Code | dBRw | Core | Fire | Leaf | Drawing ref | |
|---|---|---|---|---|---|---|
| SG44.32AD | 32 | 44 | N/F | Flush | FZD0723 | |
| SG44.33AGD | 33 | 44 | N/F | V/P | FZD0724 | |
| SG44.32A30D | 32 | 44 | 30 Min | Flush | FZD0725 | |
| SG44.33A30GD | 33 | 44 | 30 Min | V/P | FZD0726 | |
| SG54.35AD | 35 | 54 | N/F | Flush | FZD0727 | |
| SG54.35AGD | 35 | 54 | N/F | V/P | FZD0728 | |
| SG54.35A60D | 35 | 54 | 30/60 Min | Flush | FZD0729 | |
| SG54.35A60GD | 35 | 54 | 30/60 Min | V/P | FZD0730 | |
| SGFK54.36A60D | 36 | 54 | 60 Min | Flush | FZD0744 | |
| SGFK54.36A60GD | 36 | 54 | 60 Min | V/P | FZD0745 | |
| SGFS54.40A60D | 40 | 54 | 60 Min | Flush | FZD0746 | |
| SGFS54.39A60GD | 39 | 54 | 60 Min | V/P | FZD0747 | |
| SGFS59.44A60D | 44 | 59 | 60 Min | Flush | FZD0748 | |
| SGFS59.41A60GD | 41 | 59 | 60 Min | V/P | FZD0749 |
Timber & MDF Frame - Glass Acoustics
Review the glass acoustics data below and download the test reports for more information.
| Glazed Screens Non FD | |||||||
| Code | dBRw | Glass | Nominal Thickness |
Fire Rating | BS EN 12600- 02 | BS6206- 1981 | DRW Ref |
| GS6.8A36 | 36(0;-3) | GPS6.8 | 7mm | N/A | 1B1 | Class A | GS6.8A36 |
| GS8.8A37 | 37(0;-2) | GPS8.8 | 9mm | N/A | 1B1 | Class A | |
| GS10.8A39 | 39(-1;-3) | GPS10.8 | 11mm | N/A | 1B1 | Class A | |
| GS12.8A40 | 40(-1;-3) | GPS12.8 | 13mm | N/A | 1B1 | Class A | |
| GS16.8A41 | 41(-1;-2) | GPS16.8 | 17mm | N/A | 1B1 | Class A | |
| Glazed Fire Screens (FD Rated) | |||||||
| Code | dBRw | Glass | Nominal Thickness |
Fire Rating | BS EN 12600- 02 | BS6206- 1981 | DRW Ref |
| GFP7-30.0-34 | 34(0;-3) | GFP7 | 7.9mm | 30/0 | 3B3 | Class C | |
| GFP12-60.0-36 | 36(-1;-3) | GFP12 | 12.3mm | 60/0 | 2B2 | Class B |
|
| GFP16-60.30-39 | 39(-1;13) | GFP16 | 17.3mm | 60/30 | 2B2 | Class B | |
| GFP25-60.60-40 | 40(-1;-3) | GFP25 | 26.6mm | 60/60 | 1B1 | Class A | |
| GFP25eg-60.60-43 | 43(-1;-4) | GFP25eg | 30.4mm | 60/60 | 1B1 | Class A | |
