FD90 Fire Doors & Frames

Delivering 90 minutes of certified fire resistance, our FD90 doors and frames provide enhanced safety with sophisticated aesthetics for demanding environments.

Quality product
Exceptional timber doors & joinery crafted with precision.
Sustainably made
Support your sustainability goals with locally-made FSC-certified products.
Assured safety
Industry-leading certification & knowledge you can count on.
On time, every time
Reliable on time delivery keeping your projects perfectly on track.
Single doors
  • Primary test evidence available
  • Unique fire certificate & IFCC tamper-proof label

Choose from our range of FD90 single-door assemblies with optional solid side panels or overpanels.

These doors feature a high-quality face finish with bespoke handcrafted real wood veneers or commercially available decorative laminates.

Designed to meet fire-rated standards, the product complies with BS 476-22 fire resistance regulations, providing 90 minutes of fire protection as a non-load-bearing system.

Technical Specifications

Fire performance
To BS 476-22, 90 minutes
Smoke control
To BS 476-31-1, 90 minutes
Acoustic performance
Not available
Structural performance
FCW door core psi Min 900 (modulus of rupture) psi Min 1586 (compressive strength)
FCH door core Operational & Durability test to DD171, EN 1191, EN 1192, EN 947, EN 949 & EN 950 FCW door core Modulus of rupture (ASTM c 133)psi. Min 900 Compressive Strength (ASTM c 109-93)psi Min 1586
Embodied carbon
Not available
Core
Average bulk density 630kgs / m3
Range of timber-based core with average bulk density 630kgs / m3 Weight 64mm; Nom 40kgs / m2 and Mineral/Tectonite cores with average bulk density 288 - 1000kgs / m3 Weight 59mm; Nom 20kgs / m2
Frame compatibility
Hardwood, steel or composite
Warranty
10 years
Country of manufacture
United Kingdom
Sustainable sourcing
FSC® up to 70%
FSC® certified products available on request
Finishes
Wood veneer: Two coats high solid ultra violet (uv) cured lacquer, clear, 20% gloss / other. Veneer standards available: Ash/Cherry/Oak/St. Beech/Maple/American Black/Walnut/others (all available in FSC) Cut: Crown/Quarter/Rift/other. Match: Book/Random/Slip/Quarter/other. Grain direction: Vertical/Horizontal/Inlay/other. Laminate: to conform to EN 438 & ISO 4586. Primed: Forza primed coat (FPC) for painting by others. Painted: RAL, BS 4800, Pantone colors. Standard sheen 20% gloss

Customisation

Vision Panels
Choose from a range of FD90 approved vision panel designs, bespoke designs available on request.
Frames

Forza FD90 frames are typically made from hardwood (Min density 640 Kg/m³), and also available in composite material (min density 1000 Kg/m³).

If you wish to have a side panel, you’ll need to ensure you’re fitting your door into a composite frame only.

Delivery options: Available assembled, unassembled or pre-assembled and disassembled for transport purposes.

Elevations
All FD90 single door leaves are available with transom overhead overpanel from any of the options below.
Ironmongery

Select from a comprehensive range of high-quality ironmongery, certified and approved for use with timber, steel, or composite FD90 doors and frames, ensuring compliance with industry standards. Read the below guide for more detail.

Ironmongery compatibility check & guidance: we will check whether your ironmongery is compliant and advise if you need to make a change to your design.

Milling service: we offer machine-finished precise milling for all your locks, hinges, closers and more, be sure to include it in your quote request.

Double doors
  • Primary test evidence available
  • Unique fire certificate & IFCC tamper-proof label

Choose from our range of FD90 double-door assemblies with optional solid side panels or overpanels.

These doors feature a high-quality face finish with bespoke handcrafted real wood veneers or commercially available decorative laminates.

Designed to meet fire-rated standards, the product complies with BS 476-22 fire resistance regulations, providing 90 minutes of fire protection as a non-load-bearing system.

Technical Specifications

Fire performance
To BS 476-22, 90 minutes
Smoke control
To BS 476-31-1, 90 minutes
Acoustic performance
Not available
Structural performance
FCW door core psi Min 900 (modulus of rupture) psi Min 1586 (compressive strength)
FCH door core Operational & Durability test to DD171, EN 1191, EN 1192, EN 947, EN 949 & EN 950 FCW door core Modulus of rupture (ASTM c 133)psi. Min 900 Compressive Strength (ASTM c 109-93)psi Min 1586
Embodied carbon
Not available
Core
Average bulk density 630kgs / m3
Range of timber-based core with average bulk density 630kgs / m3 Weight 64mm; Nom 40kgs / m2 and Mineral/Tectonite cores with average bulk density 288 - 1000kgs / m3 Weight 59mm; Nom 20kgs / m2
Frame compatibility
Hardwood, steel or composite
Warranty
10 years
Country of manufacture
United Kingdom
Sustainable sourcing
FSC® up to 70%
FSC® certified products available on request
Finishes
Wood veneer: Two coats high solid ultra violet (uv) cured lacquer, clear, 20% gloss / other. Veneer standards available: Ash/Cherry/Oak/St. Beech/Maple/American Black/Walnut/others (all available in FSC) Cut: Crown/Quarter/Rift/other. Match: Book/Random/Slip/Quarter/other. Grain direction: Vertical/Horizontal/Inlay/other. Laminate: to conform to EN 438 & ISO 4586. Primed: Forza primed coat (FPC) for painting by others. Painted: RAL, BS 4800, Pantone colors. Standard sheen 20% gloss

Customisation

Vision Panels
Choose from a range of FD90 approved vision panel designs, bespoke designs available on request.
Frames

Forza FD90 frames are typically made from hardwood (Min density 640 Kg/m³), and also available in composite material (min density 1000 Kg/m³).

If you wish to have a side panel, you’ll need to ensure you’re fitting your door into a composite frame only.

Delivery options: Available assembled, unassembled or pre-assembled and disassembled for transport purposes.

Elevations
All FD90 double door leaves are available with transom overhead overpanel, see the drawing example below.
Ironmongery

Select from a comprehensive range of high-quality ironmongery, certified and approved for use with timber, steel, or composite FD90 doors and frames, ensuring compliance with industry standards. Read the below guide for more detail.

Ironmongery compatibility check & guidance: we will check whether your ironmongery is compliant and advise if you need to make a change to your design.

Milling service: we offer machine-finished precise milling for all your locks, hinges, closers and more, be sure to include it in your quote request.

Designed for internal use, this product is approved under the IFC Field of Application report PAR/10918/01 for installation within timber, composite, and steel frames. It is specifically suited for the UK interior fit-out construction industry.

Each Forza fire door is equipped with a unique IFCC label, providing a complete audit trail of its manufacture and certifying its fire integrity performance.

Vision panels are fitted with laminated or ceramic glass to achieve FD90/0, and FD90/60. Additional vision panel styles, including circular, and rounded slimline, are also available, some glass types may not be suitable for installation in non-rectangular configuration.

Popular Veneers & Finishes

Discover some of our most popular veneers and finishes, designed to suit every taste and enhance any space.

Niveus

Eucalyptus

Terracotta

F4161

American Black Walnut

Walnut

Albus

Ash

Artichoke

F0800

Reed Green

U599 PM

Piceus

Ash

Imber

Mulitilaminar (Oak)

Terra

Ash

Misty Blue

U502 ST9

Olive Ash

Ash

Solid Cashmere Grey

U7021 ST9

Crown Cut Beech

Beech

Vesperi

Multilaminar (Poplar)

Aged Ash

F8844

Furvus

Ash

Rotary Cut Kevasingo

Kevasingo

Alpino

F1040

White Elm

Elm

Macassar Ebony

Ebony

Get inspired

Discover endless possibilities in our design gallery, showcasing how quality materials and expert craftsmanship come together to create awesome spaces.

  • Timber Doors & Screens at No. 1 Smart's Place, Covent Garden with GPL Projects
  • Timber Fire Door with Side Leaf & Lozenge Vision Panel at Uncommon Holborn | Pace Interiors
  • Timber Doors & Screens at No. 1 Smart's Place, Covent Garden with GPL Projects
  • Double Timber Fire Doors & Lozenge Vision Panels at Uncommon Holborn | Pace Interiors
  • Timber Doors & Screens at No. 1 Smart's Place, Covent Garden with GPL Projects
  • Eucalyptus Timber Doors at Sandbanks Luxury Homes | LG Building
  • Timber Door fitted into Glass Partition
  • Timber Washrooms at 1 Knightsbridge | HK Architects
  • Painted Timber Fire Doors at Uncommon Holborn | Pace Interiors
  • Timber & Glass Partition
  • Timber Doors at FORA Chancery House
  • Timber Doors & Screens at No. 1 Smart's Place, Covent Garden with GPL Projects
  • Timber Fire Door in Kitchen at Canopy Hilton Hotel
  • Timber Fire Door at Canopy Hilton Hotel
  • Timber Door & Screen at FORA Chancery House
Ready to get started?
Get in touch today to discuss your project with our expert team.

FAQs

Get quick answers to the most commonly asked questions.
Can you cut aperture holes on a flush door leaf on-site?

Letterbox, door viewer, air transfer grills must be tested or otherwise approved for use with Forza fire-rated doors, they must be fitted fully in accordance with manufacturer instructions including all intumescent liners and cloaking grilles/beads.

Restrictions on the maximum size and placement of any aperture, in which must also be included in the total area permitted for apertures.

Note: the installation of such items in a door leaf may compromise its performance as a smoke control door assembly.

I need EN tested doors, are your doors EN tested?

At this moment Forza is only permitted to certify fire-rated door assemblies under BS 476: 22.

We are actively developing a scope of fire-rated products under EN 1634-1.

FD90 Permitted Leaf Sizes

Review permitted leaf sizes for FD90 doors and view or download the leaf size summary graph for each of the door configurations below.
FCW / TIMBER FRAMES (FZD479)
Code
LSASD
Max HT
3578
Assoc W
1137
Max W
1463
Assoc HT
2926
Code
LSASD – t/o/p
Max HT
3578
Assoc W
1137
Max W
1463
Assoc HT
2926
Code
ULSASD
Max HT
3509
Assoc W
1115
Max W
1434
Assoc HT
2869
Code
ULSASD – t/o/p
Max HT
3509
Assoc W
1115
Max W
1434
Assoc HT
2869
Code
LSADD
Max HT
3207
Assoc W
1212
Max W
1408
Assoc HT
2816
Code
LSADD – t/o/p
Max HT
3207
Assoc W
1212
Max W
1408
Assoc HT
2816
Code
ULSADD
Max HT
3176
Assoc W
1200
Max W
1394
Assoc HT
2788
Code
ULSADD – t/o/p
Max HT
3176
Assoc W
1200
Max W
1394
Assoc HT
2788
Code Max HT Assoc W Max W Assoc HT
LSASD 3578 1137 1463 2926
LSASD – t/o/p 3578 1137 1463 2926
ULSASD 3509 1115 1434 2869
ULSASD – t/o/p 3509 1115 1434 2869
LSADD 3207 1212 1408 2816
LSADD – t/o/p 3207 1212 1408 2816
ULSADD 3176 1200 1394 2788
ULSADD – t/o/p 3176 1200 1394 2788
FCH / STEEL FRAMES (FZD474)
Code
LSASD
Max HT
2561
Assoc W
768
Max W
1024
Assoc HT
2049
Code
ULSASD
Max HT
2511
Assoc W
753
Max W
1004
Assoc HT
2009
Code Max HT Assoc W Max W Assoc HT
LSASD 2561 768 1024 2049
ULSASD 2511 753 1004 2009
FCW / COMPOSITE FRAMES (FZD476)
Code
LSASD
Max HT
3835
Assoc W
1221
Max W
1569
Assoc HT
3139
Code
LSASD - t/o/p
Max HT
3835
Assoc W
1221
Max W
1569
Assoc HT
3139
Code
ULSASD
Max HT
3761
Assoc W
1115
Max W
1539
Assoc HT
3078
Code
ULSASD - t/o/p
Max HT
3761
Assoc W
1115
Max W
1539
Assoc HT
3078
Code
LSADD
Max HT
3437
Assoc W
1301
Max W
1510
Assoc HT
3020
Code
LSADD - t/o/p
Max HT
3437
Assoc W
1301
Max W
1510
Assoc HT
3020
Code
ULSADD
Max HT
3404
Assoc W
1288
Max W
1495
Assoc HT
2990
Code
ULSADD - t/o/p
Max HT
3404
Assoc W
1288
Max W
1495
Assoc HT
2990
Code Max HT Assoc W Max W Assoc HT
LSASD 3835 1221 1569 3139
LSASD - t/o/p 3835 1221 1569 3139
ULSASD 3761 1115 1539 3078
ULSASD - t/o/p 3761 1115 1539 3078
LSADD 3437 1301 1510 3020
LSADD - t/o/p 3437 1301 1510 3020
ULSADD 3404 1288 1495 2990
ULSADD - t/o/p 3404 1288 1495 2990
FCH / TIMBER FRAMES (FZD478)
Code
LSASD
Max HT
2954
Assoc W
912
Max W
1194
Assoc HT
2389
Code
ULSASD
Max HT
2484
Assoc W
760
Max W
1001
Assoc HT
2002
Code
LSASD - t/o/p
Max HT
2954
Assoc W
912
Max W
1194
Assoc HT
2389
Code
ULSASD - t/o/p
Max HT
2484
Assoc W
760
Max W
1001
Assoc HT
2002
Code
LSADD
Max HT
2218
Assoc W
739
Max W
801
Assoc HT
2093
Code
ULSADD
Max HT
2196
Assoc W
732
Max W
793
Assoc HT
2072
Code
LSADD - t/o/p
Max HT
2218
Assoc W
739
Max W
801
Assoc HT
2093
Code
ULSADD - t/o/p
Max HT
2196
Assoc W
732
Max W
793
Assoc HT
2072
Code Max HT Assoc W Max W Assoc HT
LSASD 2954 912 1194 2389
ULSASD 2484 760 1001 2002
LSASD - t/o/p 2954 912 1194 2389
ULSASD - t/o/p 2484 760 1001 2002
LSADD 2218 739 801 2093
ULSADD 2196 732 793 2072
LSADD - t/o/p 2218 739 801 2093
ULSADD - t/o/p 2196 732 793 2072
